Offer the board's ESC connector for a Smart ESC in the Outputs tab

[MrScothh]

The Configurator side of iNavFlight/inav#12087, which lets a Spektrum Smart ESC run on the ESC connector of the few boards that can route a UART's TX there (NEXUS, NEXUS X/XR, Vantac RF007). It was asked for in iNavFlight/inav#11184.

What changes

• MSP2_INAV_ESC_SRXL2_STATUS: reads the board's connectors that the firmware appends (a count, then the serial port identifier behind each). Older firmware sends none, and then nothing below appears.
• Outputs tab, with the ESC protocol SRXL2 on a board that reports a connector: a toggle "ESC on the board's ESC connector (uses UARTn)", bound to the new setting esc_srxl2_connector, off by default. The SRXL2 texts then describe both routes, count the connector as motor 1 when the board uses it, and warn when the connector's UART has a function in Ports, because the firmware then leaves the connector unused.
• The board applies the toggle at startup. The count of open ports therefore follows the saved value, and while the toggle differs from it the tab says to save and reboot, whichever way it was changed.
• Ports tab: while the connector carries the ESC, its UART shows "SRXL2 via ESC connector" in the Peripherals column, locked, with the reason in the row's tooltip. The entry has an empty value, so saving the tab keeps the port free of functions, which is what the firmware needs. A UART that has a function stays editable, so it can be cleared.
• Boards without a connector, and older firmware, look and behave as before: the toggle row is dropped when the setting does not exist, and every new text depends on a connector being reported.

Tested

• SITL, with a local firmware patch that makes UART2 stand in for a connector (part of neither PR): protocol changes, the toggle on and off, UART2 with and without MSP, save and reboot, both tabs in each state, and the toggle changed without saving in both directions.
• npm test: 290 of 291 pass. The one failure, "unused MZTC writes remain unused and conservatively blocked", fails the same way on maintenance-10.x.

Screenshots (SITL, UART2 standing in for the connector)

Outputs tab, the connector in use:

The toggle turned off and not saved yet:

Ports tab, UART2 locked while it carries the ESC:
