Build native image with Bazel #14105

Akirathan · 2025-10-02T17:30:35Z

Closes #14036

Pull Request Description

Important Notes

Checklist

Please ensure that the following checklist has been satisfied before submitting the PR:

The documentation has been updated, if necessary.
Screenshots/screencasts have been attached, if there are any visual changes. For interactive or animated visual changes, a screencast is preferred.
All code follows the
Scala,
Java,
TypeScript,
and
Rust
style guides. In case you are using a language not listed above, follow the Rust style guide.
Unit tests have been written where possible.
If meaningful changes were made to logic or tests affecting Enso Cloud integration in the libraries,
or the Snowflake database integration, a run of the Extra Tests has been scheduled.
- If applicable, it is suggested to paste a link to a successful run of the Extra Tests.

Akirathan · 2025-10-02T17:31:35Z

First attempt to build NI: bazel build :sbt_build_native_engine_distribution fails with:

Error: Default native-compiler executable 'cc' not found via environment variable PATH
Error: To prevent native-toolchain checking provide command-line option -H:-CheckToolchain

Akirathan · 2025-10-03T14:59:46Z

Which subprocesses does native-image invoke?

Let's find that out with the help of Java Flight Recorder (JFR). First, generate auxiliary native-image-args.txt by running

env ENSO_LAUNCHER=native,-ls,fast sbt engine-runner/rebuildNativeImage

Note that it is OK to kill the process right after few seconds, we are only interested in the arguments file.

The run:

native-image -J-XX:+FlightRecorder -J-XX:StartFlightRecording=filename=flight.jfr,settings=/Users/pavel/tmp/io-profile.jfc @engine/runner/target/native-image-args.txt

where io-profile.jfc is uploaded at io-profile.jfc.zip.

Then:

jfr print --events jdk.ProcessStart ./flight.jfr

The output is:

JFR output

jdk.ProcessStart {
  startTime = 16:49:54.631 (2025-10-03)
  pid = 32897
  directory = "/var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406"
  command = "/usr/bin/cc -v"
  eventThread = "main" (javaThreadId = 3)
  stackTrace = [
    com.oracle.svm.hosted.c.codegen.CCompilerInvoker.getCCompilerInfo() line: 403
    com.oracle.svm.hosted.c.codegen.CCompilerInvoker.<init>(Path) line: 75
    com.oracle.svm.hosted.c.codegen.CCompilerInvoker$DarwinCCompilerInvoker.<init>(Path) line: 290
    com.oracle.svm.hosted.c.codegen.CCompilerInvoker.create(Path) line: 87
    com.oracle.svm.hosted.NativeImageGenerator.setupNativeImage(String, OptionValues, Map, JavaMainWrapper$JavaMainSupport, SubstitutionProcessor, DebugContext) line: 1049
    ...
  ]
}

jdk.ProcessStart {
  startTime = 16:49:54.822 (2025-10-03)
  pid = 32899
  directory = "/var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406"
  command = "/usr/bin/cc -Wall -Werror -Wno-tautological-compare -o /var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406/PosixJVM_Direct /var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406/PosixJVM_Direct.c"
  eventThread = "main" (javaThreadId = 3)
  stackTrace = [
    com.oracle.svm.hosted.c.codegen.CCompilerInvoker.compileAndParseError(boolean, List, Path, Path, CCompilerInvoker$CompilerErrorHandler) line: 484
    com.oracle.svm.hosted.c.CAnnotationProcessor.compileQueryCode(Path) line: 167
    com.oracle.svm.hosted.c.CAnnotationProcessor.process(CAnnotationProcessorCache) line: 111
    com.oracle.svm.hosted.c.NativeLibraries.finish() line: 571
    com.oracle.svm.hosted.NativeImageGenerator.processNativeLibraryImports(NativeLibraries, ClassInitializationSupport) line: 1783
    ...
  ]
}

jdk.ProcessStart {
  startTime = 16:49:54.865 (2025-10-03)
  pid = 32902
  directory = "/var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406"
  command = "/var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406/PosixJVM_Direct"
  eventThread = "main" (javaThreadId = 3)
  stackTrace = [
    com.oracle.svm.hosted.c.CAnnotationProcessor.makeQuery(CAnnotationProcessorCache, String) line: 132
    com.oracle.svm.hosted.c.CAnnotationProcessor.process(CAnnotationProcessorCache) line: 117
    com.oracle.svm.hosted.c.NativeLibraries.finish() line: 571
    com.oracle.svm.hosted.NativeImageGenerator.processNativeLibraryImports(NativeLibraries, ClassInitializationSupport) line: 1783
    com.oracle.svm.hosted.NativeImageGenerator.setupNativeLibraries(HostedProviders, CEnumCallWrapperSubstitutionProcessor, ClassInitializationSupport, DebugContext) line: 1313
    ...
  ]
}

jdk.ProcessStart {
  startTime = 16:49:54.879 (2025-10-03)
  pid = 32903
  directory = "/var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406"
  command = "/usr/bin/cc -Wall -Werror -Wno-tautological-compare -ObjC -o /var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406/PosixDirectives /var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406/PosixDirectives.c"
  eventThread = "main" (javaThreadId = 3)
  stackTrace = [
    com.oracle.svm.hosted.c.codegen.CCompilerInvoker.compileAndParseError(boolean, List, Path, Path, CCompilerInvoker$CompilerErrorHandler) line: 484
    com.oracle.svm.hosted.c.CAnnotationProcessor.compileQueryCode(Path) line: 167
    com.oracle.svm.hosted.c.CAnnotationProcessor.process(CAnnotationProcessorCache) line: 111
    com.oracle.svm.hosted.c.NativeLibraries.finish() line: 571
    com.oracle.svm.hosted.NativeImageGenerator.processNativeLibraryImports(NativeLibraries, ClassInitializationSupport) line: 1783
    ...
  ]
}

jdk.ProcessStart {
  startTime = 16:49:55.050 (2025-10-03)
  pid = 32906
  directory = "/var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406"
  command = "/var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406/PosixDirectives"
  eventThread = "main" (javaThreadId = 3)
  stackTrace = [
    com.oracle.svm.hosted.c.CAnnotationProcessor.makeQuery(CAnnotationProcessorCache, String) line: 132
    com.oracle.svm.hosted.c.CAnnotationProcessor.process(CAnnotationProcessorCache) line: 117
    com.oracle.svm.hosted.c.NativeLibraries.finish() line: 571
    com.oracle.svm.hosted.NativeImageGenerator.processNativeLibraryImports(NativeLibraries, ClassInitializationSupport) line: 1783
    com.oracle.svm.hosted.NativeImageGenerator.setupNativeLibraries(HostedProviders, CEnumCallWrapperSubstitutionProcessor, ClassInitializationSupport, DebugContext) line: 1313
    ...
  ]
}

jdk.ProcessStart {
  startTime = 16:49:55.056 (2025-10-03)
  pid = 32907
  directory = "/var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406"
  command = "/usr/bin/cc -Wall -Werror -Wno-tautological-compare -o /var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406/MacTrashBin_CoreServices /var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406/MacTrashBin_CoreServices.c"
  eventThread = "main" (javaThreadId = 3)
  stackTrace = [
    com.oracle.svm.hosted.c.codegen.CCompilerInvoker.compileAndParseError(boolean, List, Path, Path, CCompilerInvoker$CompilerErrorHandler) line: 484
    com.oracle.svm.hosted.c.CAnnotationProcessor.compileQueryCode(Path) line: 167
    com.oracle.svm.hosted.c.CAnnotationProcessor.process(CAnnotationProcessorCache) line: 111
    com.oracle.svm.hosted.c.NativeLibraries.finish() line: 571
    com.oracle.svm.hosted.NativeImageGenerator.processNativeLibraryImports(NativeLibraries, ClassInitializationSupport) line: 1783
    ...
  ]
}

jdk.ProcessStart {
  startTime = 16:49:55.160 (2025-10-03)
  pid = 32910
  directory = "/var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406"
  command = "/var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406/MacTrashBin_CoreServices"
  eventThread = "main" (javaThreadId = 3)
  stackTrace = [
    com.oracle.svm.hosted.c.CAnnotationProcessor.makeQuery(CAnnotationProcessorCache, String) line: 132
    com.oracle.svm.hosted.c.CAnnotationProcessor.process(CAnnotationProcessorCache) line: 117
    com.oracle.svm.hosted.c.NativeLibraries.finish() line: 571
    com.oracle.svm.hosted.NativeImageGenerator.processNativeLibraryImports(NativeLibraries, ClassInitializationSupport) line: 1783
    com.oracle.svm.hosted.NativeImageGenerator.setupNativeLibraries(HostedProviders, CEnumCallWrapperSubstitutionProcessor, ClassInitializationSupport, DebugContext) line: 1313
    ...
  ]
}

jdk.ProcessStart {
  startTime = 16:49:55.163 (2025-10-03)
  pid = 32911
  directory = "/var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406"
  command = "/usr/bin/cc -Wall -Werror -Wno-tautological-compare -o /var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406/LibMDependencies /var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406/LibMDependencies.c"
  eventThread = "main" (javaThreadId = 3)
  stackTrace = [
    com.oracle.svm.hosted.c.codegen.CCompilerInvoker.compileAndParseError(boolean, List, Path, Path, CCompilerInvoker$CompilerErrorHandler) line: 484
    com.oracle.svm.hosted.c.CAnnotationProcessor.compileQueryCode(Path) line: 167
    com.oracle.svm.hosted.c.CAnnotationProcessor.process(CAnnotationProcessorCache) line: 111
    com.oracle.svm.hosted.c.NativeLibraries.finish() line: 571
    com.oracle.svm.hosted.NativeImageGenerator.processNativeLibraryImports(NativeLibraries, ClassInitializationSupport) line: 1783
    ...
  ]
}

jdk.ProcessStart {
  startTime = 16:49:55.199 (2025-10-03)
  pid = 32914
  directory = "/var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406"
  command = "/var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406/LibMDependencies"
  eventThread = "main" (javaThreadId = 3)
  stackTrace = [
    com.oracle.svm.hosted.c.CAnnotationProcessor.makeQuery(CAnnotationProcessorCache, String) line: 132
    com.oracle.svm.hosted.c.CAnnotationProcessor.process(CAnnotationProcessorCache) line: 117
    com.oracle.svm.hosted.c.NativeLibraries.finish() line: 571
    com.oracle.svm.hosted.NativeImageGenerator.processNativeLibraryImports(NativeLibraries, ClassInitializationSupport) line: 1783
    com.oracle.svm.hosted.NativeImageGenerator.setupNativeLibraries(HostedProviders, CEnumCallWrapperSubstitutionProcessor, ClassInitializationSupport, DebugContext) line: 1313
    ...
  ]
}

jdk.ProcessStart {
  startTime = 16:49:55.205 (2025-10-03)
  pid = 32915
  directory = "/var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406"
  command = "/usr/bin/cc -Wall -Werror -Wno-tautological-compare -o /var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406/AMD64LibCHelperDirectives /var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406/AMD64LibCHelperDirectives.c"
  eventThread = "main" (javaThreadId = 3)
  stackTrace = [
    com.oracle.svm.hosted.c.codegen.CCompilerInvoker.compileAndParseError(boolean, List, Path, Path, CCompilerInvoker$CompilerErrorHandler) line: 484
    com.oracle.svm.hosted.c.CAnnotationProcessor.compileQueryCode(Path) line: 167
    com.oracle.svm.hosted.c.CAnnotationProcessor.process(CAnnotationProcessorCache) line: 111
    com.oracle.svm.hosted.c.NativeLibraries.finish() line: 571
    com.oracle.svm.hosted.NativeImageGenerator.processNativeLibraryImports(NativeLibraries, ClassInitializationSupport) line: 1783
    ...
  ]
}

jdk.ProcessStart {
  startTime = 16:49:55.250 (2025-10-03)
  pid = 32918
  directory = "/var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406"
  command = "/var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406/AMD64LibCHelperDirectives"
  eventThread = "main" (javaThreadId = 3)
  stackTrace = [
    com.oracle.svm.hosted.c.CAnnotationProcessor.makeQuery(CAnnotationProcessorCache, String) line: 132
    com.oracle.svm.hosted.c.CAnnotationProcessor.process(CAnnotationProcessorCache) line: 117
    com.oracle.svm.hosted.c.NativeLibraries.finish() line: 571
    com.oracle.svm.hosted.NativeImageGenerator.processNativeLibraryImports(NativeLibraries, ClassInitializationSupport) line: 1783
    com.oracle.svm.hosted.NativeImageGenerator.setupNativeLibraries(HostedProviders, CEnumCallWrapperSubstitutionProcessor, ClassInitializationSupport, DebugContext) line: 1313
    ...
  ]
}

jdk.ProcessStart {
  startTime = 16:49:55.260 (2025-10-03)
  pid = 32919
  directory = "/var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406"
  command = "/usr/bin/cc -Wall -Werror -Wno-tautological-compare -I /Users/pavel/.sdkman/candidates/java/24.0.1-graal/include -I /Users/pavel/.sdkman/candidates/java/24.0.1-graal/include/darwin -o /var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406/JNIDirectives /var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406/JNIDirectives.c"
  eventThread = "main" (javaThreadId = 3)
  stackTrace = [
    com.oracle.svm.hosted.c.codegen.CCompilerInvoker.compileAndParseError(boolean, List, Path, Path, CCompilerInvoker$CompilerErrorHandler) line: 484
    com.oracle.svm.hosted.c.CAnnotationProcessor.compileQueryCode(Path) line: 167
    com.oracle.svm.hosted.c.CAnnotationProcessor.process(CAnnotationProcessorCache) line: 111
    com.oracle.svm.hosted.c.NativeLibraries.finish() line: 571
    com.oracle.svm.hosted.NativeImageGenerator.processNativeLibraryImports(NativeLibraries, ClassInitializationSupport) line: 1783
    ...
  ]
}

jdk.ProcessStart {
  startTime = 16:49:55.304 (2025-10-03)
  pid = 32922
  directory = "/var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406"
  command = "/var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406/JNIDirectives"
  eventThread = "main" (javaThreadId = 3)
  stackTrace = [
    com.oracle.svm.hosted.c.CAnnotationProcessor.makeQuery(CAnnotationProcessorCache, String) line: 132
    com.oracle.svm.hosted.c.CAnnotationProcessor.process(CAnnotationProcessorCache) line: 117
    com.oracle.svm.hosted.c.NativeLibraries.finish() line: 571
    com.oracle.svm.hosted.NativeImageGenerator.processNativeLibraryImports(NativeLibraries, ClassInitializationSupport) line: 1783
    com.oracle.svm.hosted.NativeImageGenerator.setupNativeLibraries(HostedProviders, CEnumCallWrapperSubstitutionProcessor, ClassInitializationSupport, DebugContext) line: 1313
    ...
  ]
}

jdk.ProcessStart {
  startTime = 16:49:55.308 (2025-10-03)
  pid = 32923
  directory = "/var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406"
  command = "/usr/bin/cc -Wall -Werror -Wno-tautological-compare -I/Users/pavel/.sdkman/candidates/java/24.0.1-graal/include/darwin -o /var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406/JNIHeaderDirectivesJDKLatest /var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406/JNIHeaderDirectivesJDKLatest.c"
  eventThread = "main" (javaThreadId = 3)
  stackTrace = [
    com.oracle.svm.hosted.c.codegen.CCompilerInvoker.compileAndParseError(boolean, List, Path, Path, CCompilerInvoker$CompilerErrorHandler) line: 484
    com.oracle.svm.hosted.c.CAnnotationProcessor.compileQueryCode(Path) line: 167
    com.oracle.svm.hosted.c.CAnnotationProcessor.process(CAnnotationProcessorCache) line: 111
    com.oracle.svm.hosted.c.NativeLibraries.finish() line: 571
    com.oracle.svm.hosted.NativeImageGenerator.processNativeLibraryImports(NativeLibraries, ClassInitializationSupport) line: 1783
    ...
  ]
}

jdk.ProcessStart {
  startTime = 16:49:55.346 (2025-10-03)
  pid = 32926
  directory = "/var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406"
  command = "/var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406/JNIHeaderDirectivesJDKLatest"
  eventThread = "main" (javaThreadId = 3)
  stackTrace = [
    com.oracle.svm.hosted.c.CAnnotationProcessor.makeQuery(CAnnotationProcessorCache, String) line: 132
    com.oracle.svm.hosted.c.CAnnotationProcessor.process(CAnnotationProcessorCache) line: 117
    com.oracle.svm.hosted.c.NativeLibraries.finish() line: 571
    com.oracle.svm.hosted.NativeImageGenerator.processNativeLibraryImports(NativeLibraries, ClassInitializationSupport) line: 1783
    com.oracle.svm.hosted.NativeImageGenerator.setupNativeLibraries(HostedProviders, CEnumCallWrapperSubstitutionProcessor, ClassInitializationSupport, DebugContext) line: 1313
    ...
  ]
}

jdk.ProcessStart {
  startTime = 16:49:55.358 (2025-10-03)
  pid = 32927
  directory = "/var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406"
  command = "/usr/bin/cc -Wall -Werror -Wno-tautological-compare -o /var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406/BuiltinDirectives /var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406/BuiltinDirectives.c"
  eventThread = "main" (javaThreadId = 3)
  stackTrace = [
    com.oracle.svm.hosted.c.codegen.CCompilerInvoker.compileAndParseError(boolean, List, Path, Path, CCompilerInvoker$CompilerErrorHandler) line: 484
    com.oracle.svm.hosted.c.CAnnotationProcessor.compileQueryCode(Path) line: 167
    com.oracle.svm.hosted.c.CAnnotationProcessor.process(CAnnotationProcessorCache) line: 111
    com.oracle.svm.hosted.c.NativeLibraries.finish() line: 571
    com.oracle.svm.hosted.NativeImageGenerator.processNativeLibraryImports(NativeLibraries, ClassInitializationSupport) line: 1783
    ...
  ]
}

jdk.ProcessStart {
  startTime = 16:49:55.398 (2025-10-03)
  pid = 32930
  directory = "/var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406"
  command = "/var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406/BuiltinDirectives"
  eventThread = "main" (javaThreadId = 3)
  stackTrace = [
    com.oracle.svm.hosted.c.CAnnotationProcessor.makeQuery(CAnnotationProcessorCache, String) line: 132
    com.oracle.svm.hosted.c.CAnnotationProcessor.process(CAnnotationProcessorCache) line: 117
    com.oracle.svm.hosted.c.NativeLibraries.finish() line: 571
    com.oracle.svm.hosted.NativeImageGenerator.processNativeLibraryImports(NativeLibraries, ClassInitializationSupport) line: 1783
    com.oracle.svm.hosted.NativeImageGenerator.setupNativeLibraries(HostedProviders, CEnumCallWrapperSubstitutionProcessor, ClassInitializationSupport, DebugContext) line: 1313
    ...
  ]
}

jdk.ProcessStart {
  startTime = 16:49:55.410 (2025-10-03)
  pid = 32931
  directory = "/var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406"
  command = "/usr/bin/cc -Wall -Werror -Wno-tautological-compare -I/Users/pavel/.sdkman/candidates/java/24.0.1-graal/include/darwin -o /var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406/JNIHeaderDirectives /var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406/JNIHeaderDirectives.c"
  eventThread = "main" (javaThreadId = 3)
  stackTrace = [
    com.oracle.svm.hosted.c.codegen.CCompilerInvoker.compileAndParseError(boolean, List, Path, Path, CCompilerInvoker$CompilerErrorHandler) line: 484
    com.oracle.svm.hosted.c.CAnnotationProcessor.compileQueryCode(Path) line: 167
    com.oracle.svm.hosted.c.CAnnotationProcessor.process(CAnnotationProcessorCache) line: 111
    com.oracle.svm.hosted.c.NativeLibraries.finish() line: 571
    com.oracle.svm.hosted.NativeImageGenerator.processNativeLibraryImports(NativeLibraries, ClassInitializationSupport) line: 1783
    ...
  ]
}

jdk.ProcessStart {
  startTime = 16:49:55.466 (2025-10-03)
  pid = 32934
  directory = "/var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406"
  command = "/var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406/JNIHeaderDirectives"
  eventThread = "main" (javaThreadId = 3)
  stackTrace = [
    com.oracle.svm.hosted.c.CAnnotationProcessor.makeQuery(CAnnotationProcessorCache, String) line: 132
    com.oracle.svm.hosted.c.CAnnotationProcessor.process(CAnnotationProcessorCache) line: 117
    com.oracle.svm.hosted.c.NativeLibraries.finish() line: 571
    com.oracle.svm.hosted.NativeImageGenerator.processNativeLibraryImports(NativeLibraries, ClassInitializationSupport) line: 1783
    com.oracle.svm.hosted.NativeImageGenerator.setupNativeLibraries(HostedProviders, CEnumCallWrapperSubstitutionProcessor, ClassInitializationSupport, DebugContext) line: 1313
    ...
  ]
}

jdk.ProcessStart {
  startTime = 16:49:55.471 (2025-10-03)
  pid = 32935
  directory = "/var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406"
  command = "/usr/bin/cc -Wall -Werror -Wno-tautological-compare -o /var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406/AArch64LibCHelperDirectives /var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406/AArch64LibCHelperDirectives.c"
  eventThread = "main" (javaThreadId = 3)
  stackTrace = [
    com.oracle.svm.hosted.c.codegen.CCompilerInvoker.compileAndParseError(boolean, List, Path, Path, CCompilerInvoker$CompilerErrorHandler) line: 484
    com.oracle.svm.hosted.c.CAnnotationProcessor.compileQueryCode(Path) line: 167
    com.oracle.svm.hosted.c.CAnnotationProcessor.process(CAnnotationProcessorCache) line: 111
    com.oracle.svm.hosted.c.NativeLibraries.finish() line: 571
    com.oracle.svm.hosted.NativeImageGenerator.processNativeLibraryImports(NativeLibraries, ClassInitializationSupport) line: 1783
    ...
  ]
}

jdk.ProcessStart {
  startTime = 16:49:55.511 (2025-10-03)
  pid = 32938
  directory = "/var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406"
  command = "/var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406/AArch64LibCHelperDirectives"
  eventThread = "main" (javaThreadId = 3)
  stackTrace = [
    com.oracle.svm.hosted.c.CAnnotationProcessor.makeQuery(CAnnotationProcessorCache, String) line: 132
    com.oracle.svm.hosted.c.CAnnotationProcessor.process(CAnnotationProcessorCache) line: 117
    com.oracle.svm.hosted.c.NativeLibraries.finish() line: 571
    com.oracle.svm.hosted.NativeImageGenerator.processNativeLibraryImports(NativeLibraries, ClassInitializationSupport) line: 1783
    com.oracle.svm.hosted.NativeImageGenerator.setupNativeLibraries(HostedProviders, CEnumCallWrapperSubstitutionProcessor, ClassInitializationSupport, DebugContext) line: 1313
    ...
  ]
}

jdk.ProcessStart {
  startTime = 16:49:55.513 (2025-10-03)
  pid = 32939
  directory = "/var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406"
  command = "/usr/bin/cc -Wall -Werror -Wno-tautological-compare -o /var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406/PosixWorkingDirectory_Directives /var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406/PosixWorkingDirectory_Directives.c"
  eventThread = "main" (javaThreadId = 3)
  stackTrace = [
    com.oracle.svm.hosted.c.codegen.CCompilerInvoker.compileAndParseError(boolean, List, Path, Path, CCompilerInvoker$CompilerErrorHandler) line: 484
    com.oracle.svm.hosted.c.CAnnotationProcessor.compileQueryCode(Path) line: 167
    com.oracle.svm.hosted.c.CAnnotationProcessor.process(CAnnotationProcessorCache) line: 111
    com.oracle.svm.hosted.c.NativeLibraries.finish() line: 571
    com.oracle.svm.hosted.NativeImageGenerator.processNativeLibraryImports(NativeLibraries, ClassInitializationSupport) line: 1783
    ...
  ]
}

jdk.ProcessStart {
  startTime = 16:49:55.551 (2025-10-03)
  pid = 32942
  directory = "/var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406"
  command = "/var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406/PosixWorkingDirectory_Directives"
  eventThread = "main" (javaThreadId = 3)
  stackTrace = [
    com.oracle.svm.hosted.c.CAnnotationProcessor.makeQuery(CAnnotationProcessorCache, String) line: 132
    com.oracle.svm.hosted.c.CAnnotationProcessor.process(CAnnotationProcessorCache) line: 117
    com.oracle.svm.hosted.c.NativeLibraries.finish() line: 571
    com.oracle.svm.hosted.NativeImageGenerator.processNativeLibraryImports(NativeLibraries, ClassInitializationSupport) line: 1783
    com.oracle.svm.hosted.NativeImageGenerator.setupNativeLibraries(HostedProviders, CEnumCallWrapperSubstitutionProcessor, ClassInitializationSupport, DebugContext) line: 1313
    ...
  ]
}

jdk.ProcessStart {
  startTime = 16:49:55.554 (2025-10-03)
  pid = 32943
  directory = "/var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406"
  command = "/usr/bin/cc -Wall -Werror -Wno-tautological-compare -o /var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406/RISCV64LibCHelperDirectives /var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406/RISCV64LibCHelperDirectives.c"
  eventThread = "main" (javaThreadId = 3)
  stackTrace = [
    com.oracle.svm.hosted.c.codegen.CCompilerInvoker.compileAndParseError(boolean, List, Path, Path, CCompilerInvoker$CompilerErrorHandler) line: 484
    com.oracle.svm.hosted.c.CAnnotationProcessor.compileQueryCode(Path) line: 167
    com.oracle.svm.hosted.c.CAnnotationProcessor.process(CAnnotationProcessorCache) line: 111
    com.oracle.svm.hosted.c.NativeLibraries.finish() line: 571
    com.oracle.svm.hosted.NativeImageGenerator.processNativeLibraryImports(NativeLibraries, ClassInitializationSupport) line: 1783
    ...
  ]
}

jdk.ProcessStart {
  startTime = 16:49:55.590 (2025-10-03)
  pid = 32946
  directory = "/var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406"
  command = "/var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406/RISCV64LibCHelperDirectives"
  eventThread = "main" (javaThreadId = 3)
  stackTrace = [
    com.oracle.svm.hosted.c.CAnnotationProcessor.makeQuery(CAnnotationProcessorCache, String) line: 132
    com.oracle.svm.hosted.c.CAnnotationProcessor.process(CAnnotationProcessorCache) line: 117
    com.oracle.svm.hosted.c.NativeLibraries.finish() line: 571
    com.oracle.svm.hosted.NativeImageGenerator.processNativeLibraryImports(NativeLibraries, ClassInitializationSupport) line: 1783
    com.oracle.svm.hosted.NativeImageGenerator.setupNativeLibraries(HostedProviders, CEnumCallWrapperSubstitutionProcessor, ClassInitializationSupport, DebugContext) line: 1313
    ...
  ]
}

jdk.ProcessStart {
  startTime = 16:50:53.435 (2025-10-03)
  pid = 32970
  directory = "/var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406"
  command = "/usr/bin/cc -Wl,-U,___darwin_check_fd_set_overflow -Wl,-no_compact_unwind -Wl,-exported_symbols_list -Wl,/var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406/exported_symbols.list -Wl,-x -arch arm64 -o /Users/pavel/dev/enso/built-distribution/enso-engine-0.0.0-dev-macos-aarch64/enso-0.0.0-dev/bin/enso enso.o /Users/pavel/.sdkman/candidates/java/24.0.1-graal/lib/svm/clibraries/darwin-aarch64/liblibchelper.a /Users/pavel/.sdkman/candidates/java/24.0.1-graal/lib/static/darwin-aarch64/libnet.a /Users/pavel/.sdkman/candidates/java/24.0.1-graal/lib/svm/clibraries/darwin-aarch64/libdarwin.a /Users/pavel/.sdkman/candidates/java/24.0.1-graal/lib/static/darwin-aarch64/libextnet.a /Users/pavel/.sdkman/candidates/java/24.0.1-graal/lib/static/darwin-aarch64/libnio.a /Users/pavel/.sdkman/candidates/java/24.0.1-graal/lib/static/darwin-aarch64/libmanagement_ext.a /Users/pavel/.sdkman/candidates/java/24.0.1-graal/lib/static/darwin-aarch64/libjava.a /Users/pavel/.sdkman/candidates/java/24.0.1-graal/lib/static/darwin-aarch64/libzip.a /Users/pavel/.sdkman/candidates/java/24.0.1-graal/lib/svm/clibraries/darwin-aarch64/libjvm.a -v -L/var/folders/bl/dj8f8x456nq6fvjlxz5tb_6c0000gn/T/SVM-8171376717939253406 -L/Users/pavel/.sdkman/candidates/java/24.0.1-graal/lib/static/darwin-aarch64 -L/Users/pavel/.sdkman/candidates/java/24.0.1-graal/lib/svm/clibraries/darwin-aarch64 -L/Users/pavel/.sdkman/candidates/java/24.0.1-graal/lib/svm/clibraries -L/Users/pavel/.sdkman/candidates/java/24.0.1-graal/lib/svm/macros/truffle-svm/builder -L/Users/pavel/.sdkman/candidates/java/24.0.1-graal/lib/server -Wl,-framework,CoreServices -lm -lc -Wl,-framework,CoreServices -ldl -lpthread -Wl,-framework,Foundation -lz"
  eventThread = "main" (javaThreadId = 3)
  stackTrace = [
    com.oracle.svm.hosted.image.NativeImageViaCC.runLinkerCommand(String, LinkerInvocation, List, AbstractImage$NativeImageKind) line: 138
    com.oracle.svm.hosted.image.NativeImageViaCC.write(DebugContext, Path, Path, String, FeatureImpl$BeforeImageWriteAccessImpl) line: 115
    com.oracle.svm.hosted.NativeImageGenerator.doRun(Map, JavaMainWrapper$JavaMainSupport, String, AbstractImage$NativeImageKind, SubstitutionProcessor) line: 750
    com.oracle.svm.hosted.NativeImageGenerator.run(Map, JavaMainWrapper$JavaMainSupport, String, AbstractImage$NativeImageKind, SubstitutionProcessor, EconomicSet, TimerCollection) line: 533
    com.oracle.svm.hosted.NativeImageGeneratorRunner.buildImage(ImageClassLoader) line: 545
    ...
  ]
}

TL;DR;

native-image invokes 24 subprocesses. As far as I can tell this is cc invocation to compile some auxiliary C sources to infer some capabilities, and then invoking those compiled executables. In this respect, native-image works like autoconf.

@vitvakatu do you think we can make this work from Bazel somehow?

EDIT (Answer)

@vitvakatu thinks it should be OK as far as:

C compiler toolchain will be passed to the native-image tool via env variable provided by Bazel.
- native-image should not try to resolve the toolchain itself.
As an inspiration, look into https://bazel-contrib.github.io/rules_foreign_cc/index.html

Akirathan · 2025-10-13T17:08:04Z

@vitvakatu bazel expert needed. I am trying to provide cc compiler in

enso/toolchains/sbt/run_sbt.bzl

Lines 14 to 15 in 539f2ac


           cc_toolchain = ctx.toolchains["@bazel_tools//tools/cpp:toolchain_type"]

           cc_path = cc_toolchain.cc.compiler_executable

. In my case cc_path is evaluated to external/rules_cc++cc_configure_extension+local_config_cc/cc_wrapper.sh. But this file does not exist: the command bazel build :sbt_build_native_engine_distribution is failing with:

Error: --native-compiler-path=/private/var/tmp/_bazel_pavel/737dedbf20ec237592160d5e174461b8/sandbox/darwin-sandbox/2/execroot/_main/external/rules_cc++cc_configure_extension+local_config_cc/cc_wrapper.sh does not specify a path to an executable.
Error: To prevent native-toolchain checking provide command-line option -H:-CheckToolchain

Any ideas how to convince Bazel to provide this external/../cc_wrapper.sh for the run_sbt rule?

vitvakatu · 2025-10-13T20:02:18Z

It seems you need to specify compiler files as input for the rule. See how it is done in rules_graalvm:

https://github.com/sgammon/rules_graalvm/blob/81fc9b2de33c0429b716f1bfcd3223a82c0e1085/internal/native_image/rules.bzl#L122

https://github.com/sgammon/rules_graalvm/blob/81fc9b2de33c0429b716f1bfcd3223a82c0e1085/internal/native_image/toolchain.bzl#L41

GitHub
rules_graalvm/internal/native_image/rules.bzl at 81fc9b2de33c0429b716f1bfcd3223a82c0e1085 · sgammon/rules_graalvm
Build GraalVM native binaries with Bazel. Contribute to sgammon/rules_graalvm development by creating an account on GitHub.

GitHub
rules_graalvm/internal/native_image/toolchain.bzl at 81fc9b2de33c0429b716f1bfcd3223a82c0e1085 · sgammon/rules_graalvm
Build GraalVM native binaries with Bazel. Contribute to sgammon/rules_graalvm development by creating an account on GitHub.

This forces Bazel to add the cc compiler_executable to the sandbox.

Akirathan · 2025-10-14T11:20:28Z

On 59aa5f5:

bazel build :sbt_build_native_engine_distribution builds the native image into bazel-bin/built-distribution-native directory.
bazel run run_enso_test runs sanity check by looking for the enso executable inside built-distribution-native and invoking it with --run test/Base_Tests/src/Data/Maybe_Spec.enso

… dir" This reverts commit e91757d.

Try building native image

895c4d9

Akirathan self-assigned this Oct 2, 2025

Akirathan added the CI: No changelog needed Do not require a changelog entry for this PR. label Oct 2, 2025

enso-bot bot mentioned this pull request Oct 2, 2025

Try to register only static methods during compilation #11686

Open

JaroslavTulach mentioned this pull request Oct 10, 2025

Wip/vitvakatu/bazel small jdk #14132

Closed

5 tasks

Akirathan added 2 commits October 10, 2025 14:19

C compiler path sys prop

8287ef9

C compiler path is resolved via bazel toolchain

539f2ac

Akirathan added 4 commits October 14, 2025 12:56

Set CC files as dependencies of run_sbt rule.

7ae1d8c

This forces Bazel to add the cc compiler_executable to the sandbox.

run_enso respects built distribution directory name

5d933b9

sanity check is done for native engine distribution

646131a

Use basename for the directory

59aa5f5

Akirathan added 4 commits October 14, 2025 13:40

Add rule that ensure that enso distribution was built with NI

9f2b6ce

[WIP] try to provide path to executable in built-distribution dir

e91757d

Revert "[WIP] try to provide path to executable in built-distribution…

6487ba1

… dir" This reverts commit e91757d.

Install NI dependencies on the CI

352930f

Provide feedback

Saved searches

Use saved searches to filter your results more quickly

Uh oh!

Build native image with Bazel #14105

Build native image with Bazel #14105

Uh oh!

Akirathan commented Oct 2, 2025 •

edited

Loading

Uh oh!

Akirathan commented Oct 2, 2025

Uh oh!

Akirathan commented Oct 3, 2025 •

edited

Loading

Uh oh!

Akirathan commented Oct 13, 2025

Uh oh!

vitvakatu commented Oct 13, 2025 •

edited by unfurl-links bot

Loading

Uh oh!

Akirathan commented Oct 14, 2025

Uh oh!

Reviewers

Assignees

Labels

Projects

Milestone

Development

Uh oh!

2 participants

Build native image with Bazel #14105

Are you sure you want to change the base?

Build native image with Bazel #14105

Uh oh!

Conversation

Akirathan commented Oct 2, 2025 • edited Loading Uh oh! There was an error while loading. Please reload this page.

Uh oh!

Pull Request Description

Important Notes

Checklist

Uh oh!

Akirathan commented Oct 2, 2025

Uh oh!

Akirathan commented Oct 3, 2025 • edited Loading Uh oh! There was an error while loading. Please reload this page.

Uh oh!

Which subprocesses does native-image invoke?

TL;DR;

EDIT (Answer)

Uh oh!

Akirathan commented Oct 13, 2025

Uh oh!

vitvakatu commented Oct 13, 2025 • edited by unfurl-links bot Loading Uh oh! There was an error while loading. Please reload this page.

Uh oh!

Uh oh!

Akirathan commented Oct 14, 2025

Uh oh!

Reviewers

Assignees

Labels

Projects

Milestone

Development

Uh oh!

2 participants

Akirathan commented Oct 2, 2025 •

edited

Loading

Akirathan commented Oct 3, 2025 •

edited

Loading

vitvakatu commented Oct 13, 2025 •

edited by unfurl-links bot

Loading
