docs: MCP OAuth tri-mode implementation plan (PR-cycle, no-regression, SOLID) by seanhanca · Pull Request #457 · livepeer/naap

seanhanca · 2026-08-08T07:34:32Z

Purpose

Adds MCP-OAUTH-TRIMODE-IMPL-PLAN.html — the PR-cycle implementation plan for MCP OAuth tri-mode auth. Docs only; no production code changes.

Three ways to connect: paste a Daydream sk_*, paste a pymthouse composite, or sign in via OAuth. All auth-mode selection lives in one new Auth Resolution Layer; inference, SDK, gateway and signer stay auth-agnostic (Bearer in → ResolvedCredential { plane, forwardBearer, metadata? } out).

Review verdict

Criterion	Result	Note
Complete	PASS	17 PRs, each with id · repo · real files · flag+default · acceptance · self-review · e2e · prod verify · rollback · revert-safety
Consistent	FIXED	5 drifts vs the design doc corrected; every code symbol re-verified against source
Regression-safe	PASS	12-row live matrix + INV-1…INV-6 golden tests landing before any refactor
Not over-engineered	PASS	11 explicit "deliberately NOT building" items; exactly 2 new flags; no new registry, no device flow, no runtime picker
Decoupled	PASS	`resolveAuth()` is the sole mode-selection site; `sdkCall` keeps its `apiKey: string`; 11 anti-patterns reviewers must block

The 17 PRs by track

Track 1 — invariants & resolution layer (storyboard-a3, no flag): PR-01 golden invariants · PR-02 resolveAuth() · PR-03 pmth-composite scheme (log-only)
Track 2 — OAuth head, inert (MCP_OAUTH_ENABLED unset): PR-04 PRM/AS metadata + cached-404 fix · PR-05 401 challenge · PR-06 oauth-store · PR-07 broker routes · PR-08 store lookup
Track 3 — mint providers (MCP_OAUTH_PROVIDER): PR-09 NaaP mint route · PR-10 naap provider · PR-15 pymthouse provider
Track 4 — LR / signer infra (simple-infra): PR-11 build-time guard · PR-12 isolated canary · PR-13 promotion
Track 5 — enablement: PR-14 web_ client · PR-16 connector docs · PR-17 revocation (deferred)

No-regression guarantee

Daydream sk_* → Daydream signer → BYOC orchestrator stays byte-identical. All new behavior is scoped to LR orchestrators and the pymthouse signer. Pinned by six golden invariants that land in PR-01 before any refactor:

INV-1 flag-OFF invariance — an mcp_at_*-shaped bearer with the flag unset behaves as an unrecognized opaque bearer
INV-2 sk_* byte-identity in → out
INV-3 no path emits mcp_at_* as forwardBearer; store miss ⇒ 401, never a fallthrough
INV-4 the resolution layer imports no HTTP client
INV-5 sdk-call.ts byte-unchanged across the plan
INV-6 authForRestProxy unchanged — OAuth never reaches the 10+ REST routes

Rows 1–4 of the 12-row matrix re-run on every merge in tracks 1–3. Deviation halts the plan rather than triggering a fix-forward.

Top risks

R1 regression on the Daydream plane — low likelihood, critical impact; invariants land first, no PR touches key_routing.py
R3 agent/implementation complexity — 17 PRs across 3 repos; one PR = one card, and editing an invariant test is an escalation tripwire
R10 durable store — Storyboard had no KV; now funded, with AP-9 (in-memory map) and AP-11 (public blob) blocking
R9 the cached 404 — .well-known serves its 404 immutable for 24h, so a flag flip would not reach clients; PR-04 fixes headers before any flip
R6 credential leakage — minted keys never returned to clients; secret scan is a merge precondition on every PR

Owner decisions folded in (2026-08-08)

KV: provision it. Former blocker OA-6 resolved; PR-06→PR-08 un-gated. Provisioning is now task T-KV with acceptance criteria (encryption at rest, server-side TTL, per-user isolation) gating PR-06's merge.
Metering: de-scoped. Usage-API debit reads deferred as FU-1. Proof bar for a billed call is now signer 200 + numTickets in range + real asset URL.

Remaining open asks

PYMTHOUSE_M2M_CLIENT_SECRET — still required. The supplied m2m_… value is a client id. Verified in code: createPymthouseApiKey() and the user-upsert both call readM2mAuthHeader(), which throws 503 without both halves. This blocks the mint path (PR-09/PR-10/PR-15). The metering de-scope lowers the verification bar but does not unblock these.
T-KV — provision the KV and sign off its acceptance criteria.
pymthouse web_ confidential client for Scenario B (public app_ clients cannot do authorization_code).
LR gateway rebuild — deployed image lacks live_runner.py, so call_runner is missing.
Signer session-payment verification — whether paygen supports repeated calls under one MCP session.

No secrets appear in the document or this PR.

Made with Cursor

…ass 3) The previous pass ended mid-document: sections 5-10 were missing while the review verdict already claimed them. This writes the PR breakdown (17 PRs across 5 tracks), the PR-cycle loop, the 12-row regression matrix, risks, rollout with an explicit stop line, and the owner asks. Two findings from verifying claims against source rather than assuming: - The supplied pymthouse M2M value is a client id, not a secret. Both the composite mint and every usage/metering read use HTTP Basic id:secret and fail closed without both halves, so the client secret remains a hard blocker for the mint providers (OA-1). - Storyboard has no durable KV; its only durable store is public blob storage. The oauth-store binds a billing credential, so neither an in-memory map nor blob is acceptable. Raised as blocker OA-6 and anti-pattern AP-11, gating phase 1 on a provisioning decision. Regression stance is unchanged and now testable: Daydream sk_* to Daydream signer to BYOC orchestrator stays byte-identical, pinned by INV-1..INV-6 landing before any refactor. No credentials appear in this document. Co-authored-by: Cursor <cursoragent@cursor.com>

Two owner decisions, applied consistently across the plan. KV (was blocker OA-6): a real private KV will be provisioned rather than shipping P0-passthrough only. This un-gates PR-06 through PR-08 and all of phase 1. Provisioning becomes owner task T-KV with acceptance criteria: resource reachable from prod and preview, env wired with clean boot when absent, encryption at rest, server-side TTL under 24h for token bindings, per-user namespacing with no scan surface, and the credential never returned to the client. Recommendation is Vercel KV / Upstash Redis for native key TTL. AP-9 (in-memory map) and AP-11 (public blob) remain blocking anti-patterns: funding the right answer does not license a cheaper one. The stop line is demoted to a contingency. Metering: usage-API debit reads are deferred as follow-up FU-1. The proof bar for a billed call becomes signer 200, numTickets in range, and a real asset URL. Verified against source that this does NOT unblock the mint path: createPymthouseApiKey and the user-upsert both call readM2mAuthHeader, which throws 503 without both the M2M client id and secret, so PR-09/PR-10/PR-15 stay blocked. Only the verification bar moves; the billed tail is testable solely because RS-1 supplied an already-minted composite. Daydream sk_* to Daydream signer to BYOC orchestrator remains byte-identical and pinned by INV-1..INV-6. No credentials appear in this document. Co-authored-by: Cursor <cursoragent@cursor.com>

vercel · 2026-08-08T07:34:34Z

The latest updates on your projects. Learn more about Vercel for GitHub.

Project	Deployment	Actions	Updated (UTC)
naap-platform	Ready	Preview	Aug 9, 2026 4:52am

github-actions · 2026-08-08T07:34:40Z

⚠️ This PR is very large (2739 lines changed). Please split it into smaller, focused PRs if possible.

…entation Found while implementing PR-01 against the real repo: - The planned test path lib/mcp-server/__tests__/ would never run; the vitest config only includes tests/unit, tests/sim and the creative-kit package. Corrected to tests/unit/mcp-oauth-auth-invariants.test.ts. - Clarified that storyboard-a3 is the local working-copy name while the GitHub remote is livepeer/storyboard, verified via git remote -v. - Marked PR-01 as shipped (livepeer/storyboard#868). Co-authored-by: Cursor <cursoragent@cursor.com>

Track 1 on storyboard main reject unbound mcp_at_* unconditionally; remove the flag-OFF opaque-forward contradiction, mark PRs MERGED with SHAs, and require a single worker for Track 2+ auth work. Co-authored-by: Cursor <cursoragent@cursor.com>

seanhanca · 2026-08-08T16:01:15Z

Doc sync: aligned plan with merged Track 1 Auth Resolution contract.

Unbound mcp_at_* is fail-closed by resolveAuth always (not gated on MCP_OAUTH_ENABLED); removed §7 row 9 / §4.2 flag-OFF opaque-forward contradiction.
Track 1 MERGED: #868→7e39673f, #869→788202b6, #870→667afd74.
PR-08 note: bound → composite when oauth-store lands; unbound still fail-closes.
Process: Track 2+ single worker on auth code (no parallel agents) to avoid R3 collision.

No Track 2 implementation in this push.

Record PR-04/PR-05 merge SHAs, PR-06 open behind T-KV, and the project-scoped token limitation blocking Upstash Marketplace create.

Owner-provisioned store smoke-tested; PR-06 merge gate cleared. Co-authored-by: Cursor <cursoragent@cursor.com>

Record PR-06/07/08 merge SHAs, T-KV already signed off, PR-09 naap#458 open, and OA-1 secret received with NaaP Preview env-wire still pending. Co-authored-by: Cursor <cursoragent@cursor.com>

Co-authored-by: Cursor <cursoragent@cursor.com>

Grounded summary of Tracks 1–3 / T-KV: merged PR table with SHAs, honest FULLY/PARTIALLY/NOT VERIFIED prod curl evidence, Preview env wiring steps (names only), and user-story enablement boundaries. Co-authored-by: Cursor <cursoragent@cursor.com>

seanhanca · 2026-08-08T21:06:25Z

Added MCP-OAUTH-TRIMODE-STATUS.html — verified status + ops wiring guide (no secrets).

Merged PR table (storyboard #868–876, naap feat(mcp-oauth): PR-09 — internal MCP mint route (test-app only) #458) with SHAs
Prod curl evidence labeled FULLY / PARTIALLY / NOT VERIFIED
Preview env names + flag-flip stop-line before MCP_OAUTH_ENABLED=1
User stories: enabled now vs after ops wire vs still unsupported

File: https://github.com/livepeer/naap/blob/feat/mcp-oauth-tri-mode-plan/MCP-OAUTH-TRIMODE-STATUS.html

STATUS + plan: PR-11/12/15/16 + NaaP login bridge merged; remaining work is Preview env, web_ client, LR canary deploy, and deferred PR-13/17/FU-1.

seanhanca · 2026-08-09T01:19:43Z

Implementation complete (code) — ops remaining

All IMPLEMENT NOW PRs from Tracks 4–5 + NaaP login bridge are merged. Prod MCP_OAUTH_ENABLED remains OFF (rechecked 2026-08-09: well-known 404 max-age=60; broker authorize 404).

PR	Class	Result
PR-11 build guard	impl	simple-infra#125 → `ae0f3f5a`
PR-12 canary overlay	impl (config)	simple-infra#126 → `4a7bdb48` — deploy/e2e still ops
PR-13 promote LR	deferred	blocked on PR-12 green + OA-4
PR-14 `web_` client	ops only	§4.6 in STATUS
PR-15 pymthouse provider	impl	storyboard#878 → `245879a0`
PR-16 connector docs	impl	storyboard#879 → `37db2dac`
PR-17 revocation	deferred	N11
NaaP login bridge	impl	naap#459 → `7dde3685`
FU-1 metering	deferred	unchanged

INV: storyboard main @ 37db2dac — INV + naap + pymthouse provider unit tests 34 passed.

User ops next (guides in MCP-OAUTH-TRIMODE-STATUS.html): §4.1–4.5 Preview mint/flag; §4.6 Scenario B web_; §4.7 LR canary deploy (owner). Do not set prod MCP_OAUTH_ENABLED=1.

STATUS + plan HTML updated on this branch.

Flag ON confirmed (AS/PRM 200); PKCE blocked on Storyboard client redirect allowlist + NaaP login mcp_oauth_invalid. Tripwire: delete MCP_OAUTH_ENABLED. Co-authored-by: Cursor <cursoragent@cursor.com>

seanhanca · 2026-08-09T03:07:32Z

Scenario A Production flip probe (2026-08-09T03:05–03:07Z) — BLOCKED

Flip OFF now: delete Storyboard Production MCP_OAUTH_ENABLED → Redeploy (public broker is live until then).

Evidence

Check	Result
AS / PRM `/.well-known/…`	200 (flag ON)
`/api/mcp/oauth/authorize`	not 404; 400 `redirect_uri not allow-listed` for all probed client callbacks
NaaP `/login?mcp_oauth=1&redirect_uri=https://storyboard.daydream.monster/api/mcp/oauth/callback`	307 → `error=mcp_oauth_invalid`
`POST /api/internal/mcp/mint` wrong Bearer	401 `unauthorized` (mint wired)
Signer `/healthz`	200 OK
Unbound `mcp_at_*`	401 fail-closed
PKCE → token → `create_media`	not run

One-line fixes (if you re-open the window)

NaaP Production: MCP_INTERNAL_MINT_ALLOWLIST=https://storyboard.daydream.monster + MCP_OAUTH_REDIRECT_ALLOWLIST=https://storyboard.daydream.monster/api/mcp/oauth/callback → Redeploy (bridge must not return mcp_oauth_invalid).
Storyboard Production: set MCP_OAUTH_REDIRECT_ALLOWLIST for the MCP client callback(s) (e.g. http://127.0.0.1:*,http://localhost:* and/or Claude) → Redeploy (authorize must 302, not 400).

Report: MCP-OAUTH-TRIMODE-E2E-REPORT.html (updated on feat/mcp-oauth-tri-mode-plan).

Scenario A re-probe: flag ON + NaaP allowlist OK; e2e still BLOCKED on Storyboard MCP_OAUTH_REDIRECT_ALLOWLIST. Remind flip OFF after test. Co-authored-by: Cursor <cursoragent@cursor.com>

seanhanca · 2026-08-09T03:13:13Z

Prod host correction + Scenario A re-probe (2026-08-09T03:11Z)

Correct Production MCP/OAuth host: https://agent.livepeer.org (not storyboard.daydream.monster).

Probe results

Check	Result
`GET /.well-known/oauth-authorization-server`	200 — flag ON, issuer `https://agent.livepeer.org`
`GET /.well-known/oauth-protected-resource`	200 — broker metadata live
`GET /api/mcp/oauth/authorize` (localhost / agent callback)	400 `redirect_uri not allow-listed`
NaaP login bridge `redirect_uri=https://agent.livepeer.org/api/mcp/oauth/callback`	307 + `naap_mcp_oauth_pending` cookie — not `mcp_oauth_invalid` (NaaP allowlist OK)
Mint wrong Bearer + `X-Mcp-Caller-Origin: https://agent.livepeer.org`	401 unauthorized (wired)
Unbound `mcp_at_*`	401 + `resource_metadata=https://agent.livepeer.org/...`
Signer `/healthz`	200

E2E status: BLOCKED (not GREEN)

One-line fix: on Storyboard Production set
MCP_OAUTH_REDIRECT_ALLOWLIST=http://127.0.0.1:*,http://localhost:* (+ real MCP client callbacks) → Redeploy → authorize must 302 to NaaP. Then re-run maximal Scenario A.

Corrected Storyboard Production env (copy-paste)

NAAP_MCP_ORIGIN=https://operator.livepeer.org
NAAP_MCP_MINT_URL=https://operator.livepeer.org/api/internal/mcp/mint
MCP_INTERNAL_MINT_SECRET=<SAME_AS_NAAP>
MCP_INTERNAL_MINT_CALLER_ORIGIN=https://agent.livepeer.org
MCP_OAUTH_PROVIDER=naap
MCP_OAUTH_BILLING_APP_ID=app_98575870d7ae33589a3f0660
MCP_OAUTH_ENABLED=1
MCP_OAUTH_REDIRECT_ALLOWLIST=http://127.0.0.1:*,http://localhost:*

(Var name MCP_OAUTH_REDIRECT_ALLOWLIST confirmed in Storyboard oauth-broker.ts — fail-closed if empty.)

NaaP Production already correct:
MCP_INTERNAL_MINT_ALLOWLIST=https://agent.livepeer.org
MCP_OAUTH_REDIRECT_ALLOWLIST=https://agent.livepeer.org/api/mcp/oauth/callback

Remind

Flip OFF after test — delete Production MCP_OAUTH_ENABLED + Redeploy (public broker is live while ON).

Docs updated on feat/mcp-oauth-tri-mode-plan (STATUS §9 + E2E report). No secrets committed.

…man SSO Storyboard Production MCP_OAUTH_REDIRECT_ALLOWLIST is live: authorize PKCE returns 302 to NaaP login (not 400) for localhost and agent.livepeer.org callback. Login bridge still sets naap_mcp_oauth_pending. Playwright reached GitHub OAuth login; no E2E session in agent env, so bound mcp_at_* / create_media not proven. Flip OFF Production MCP_OAUTH_ENABLED now. Co-authored-by: Cursor <cursoragent@cursor.com>

seanhanca · 2026-08-09T03:19:25Z

Scenario A prod re-probe (allowlist fixed) — BLOCKED (not GREEN)

Window: 2026-08-09T03:16–03:18Z against https://agent.livepeer.org
Commit: 7309acf1 on feat/mcp-oauth-tri-mode-plan
Report: MCP-OAUTH-TRIMODE-E2E-REPORT.html

Evidence

Check	Result
AS / PRM well-known	200 (flag ON)
Authorize PKCE (`127.0.0.1` / `localhost` / agent callback)	302 → `operator.livepeer.org/login?mcp_oauth=1…` (prior 400 redirect allowlist FIXED)
NaaP login bridge + agent callback	307 + `naap_mcp_oauth_pending` — not `mcp_oauth_invalid`
Evil redirect	still `mcp_oauth_invalid`
Playwright	reached NaaP login → GitHub OAuth page; human SSO required (no `E2E_USER_*` in agent env)
Mint wrong-Bearer	401
Signer `/healthz`	200
Unbound `mcp_at_*`	401 fail-closed
Bound session / `create_media` asset	not run

Why not GREEN

Redirect allowlist is fixed and the broker head works through NaaP login. Full Scenario A proof bar (bound mcp_at_* → create_media → real asset) still needs a human to complete Google/GitHub/email login, or E2E_USER_EMAIL / E2E_USER_PASSWORD provided in-agent.

Flip OFF now

Delete Production MCP_OAUTH_ENABLED on Storyboard (agent.livepeer.org) → Redeploy to close the public broker window — whether or not SSO is finished later.

Record 3× Google SSO → opaque callback access_denied, live curls, and the Storyboard PR that returns a safe reason enum for the next retry. Co-authored-by: Cursor <cursoragent@cursor.com>

seanhanca · 2026-08-09T04:04:59Z

Scenario A prod update — opaque `access_denied` + storyboard reason ship

Host: https://agent.livepeer.org (flag ON: AS/PRM 200, authorize localhost PKCE → 302 NaaP login).

Human evidence: Google SSO succeeded; Storyboard callback returned {"error":"access_denied"} (400) with state=st_…&external_user_id=… three times. Prior analysis: NaaP mint was never called — throw is in Storyboard completeUpstreamCallback before fetch(mint) (state miss or pre-mint config). Fake-state curl reproduces the same opaque JSON (cannot distinguish yet).

Throw inventory (Storyboard broker complete path):

Failure	Env / condition
`invalid_or_expired_state`	Redis pending miss/TTL/one-shot (`KV_REST_API_` or `UPSTASH_REDIS_REST_`)
`kv`	store unset → `OauthStoreUnavailableError`
`identity`	missing `external_user_id`/`code`; or `NAAP_MCP_ORIGIN` / identity exchange
`mint_config`	`MCP_OAUTH_BILLING_APP_ID` or `PYMTHOUSE_PUBLIC_CLIENT_ID` ≠ `app_98575870d7ae33589a3f0660`; or missing `NAAP_MCP_MINT_URL` + `MCP_INTERNAL_MINT_SECRET` + `MCP_INTERNAL_MINT_CALLER_ORIGIN`
`mint_http_<n>`	mint HTTP non-OK
`mint_failed`	non-composite response

Shipped + merged: livepeer/storyboard#880 — callback now returns { error: "access_denied", reason: "<safe enum>" } + server log. Production redeploy in progress (probe still opaque at comment time).

E2E report updated + pushed on this branch (MCP-OAUTH-TRIMODE-E2E-REPORT.html / STATUS).

Next user action (ONE retry after prod shows `reason`)

Confirm deploy: curl -sS 'https://agent.livepeer.org/api/mcp/oauth/callback?state=st_fake&external_user_id=u1' → must include "reason":"invalid_state".
Fresh authorize (durable local PKCE listener) → Google/GitHub login → if fail, paste the new JSON body (with reason).
Flip OFF reminder: when the window ends, delete Production MCP_OAUTH_ENABLED on Storyboard → Redeploy.

Vercel runtime logs: 403 from this worker (no project token) — reason enum unblocks without needing logs.

seanhanca · 2026-08-09T04:06:41Z

Production reason enum is LIVE

Confirmed on agent.livepeer.org after storyboard#880 Production deploy (32db8d04):

{"error":"access_denied","reason":"invalid_state"}

(fake-state probe)

ONE retry URL (fresh pending, ~10 min TTL)

Start a local PKCE listener on 127.0.0.1:54321 first, then open:

https://operator.livepeer.org/login?mcp_oauth=1&state=st_7cqoNYP1jzAlmSUSTE1UXsZKjPr_H5Hqm8j_cdjXStc&redirect_uri=https%3A%2F%2Fagent.livepeer.org%2Fapi%2Fmcp%2Foauth%2Fcallback

Complete Google (or GitHub).

Success → browser hits http://127.0.0.1:54321/callback?code=mcp_ac_… — paste that URL.
Failure → paste the JSON body from the Storyboard callback tab (must include reason).

Flip OFF after window: delete Production MCP_OAUTH_ENABLED → Redeploy.

Co-authored-by: Cursor <cursoragent@cursor.com>

seanhanca · 2026-08-09T04:09:18Z

Fresh retry ready (reason codes LIVE + durable listener)

Open now (~10 min Redis TTL):
https://operator.livepeer.org/login?mcp_oauth=1&state=st_1EZLZJVtjpR8XytZK4GUqDtI1PG8x6U7jzDr_tu9D2o&redirect_uri=https%3A%2F%2Fagent.livepeer.org%2Fapi%2Fmcp%2Foauth%2Fcallback

Local PKCE listener: http://127.0.0.1:54321/callback (running)
Pending state: st_1EZLZJVtjpR8XytZK4GUqDtI1PG8x6U7jzDr_tu9D2o
Authorize: https://agent.livepeer.org/api/mcp/oauth/authorize?response_type=code&client_id=cursor-e2e&redirect_uri=http%3A%2F%2F127.0.0.1%3A54321%2Fcallback&code_challenge=AUz2sVoWdnB1c_8cg2EBM3DfLZcf1I-6EEoyzC5OI7g&code_challenge_method=S256&state=H3sH0KwQlOJul5zgcS9laG0a1NGXEEJ3

Complete Google/GitHub once. Success → agent auto token-exchange + create_media. Failure → paste JSON with reason.

Flip OFF after window: delete Production MCP_OAUTH_ENABLED → Redeploy.

…retry Co-authored-by: Cursor <cursoragent@cursor.com>

Co-authored-by: Cursor <cursoragent@cursor.com>

seanhanca · 2026-08-09T04:19:19Z

Fresh retry URL (re-minted — prior pending expired unused)

Open now:
https://operator.livepeer.org/login?mcp_oauth=1&state=st_v6x5cUAfR6yMqWPMo5zRt4elv5uW1h7SxpXd9-pcbcM&redirect_uri=https%3A%2F%2Fagent.livepeer.org%2Fapi%2Fmcp%2Foauth%2Fcallback

Listener: http://127.0.0.1:54321/callback (running, 20m wait)
Pending: st_v6x5cUAfR6yMqWPMo5zRt4elv5uW1h7SxpXd9-pcbcM
Do not reuse older login links.

On fail paste JSON with reason. Flip OFF after: delete Production MCP_OAUTH_ENABLED.

Record agent.livepeer.org SSO → mcp_ac → mcp_at token 200 evidence, invalid_grant on code reuse, and Flip-OFF reminder. create_media asset pending optional re-login after harness action=generate patch. Co-authored-by: Cursor <cursoragent@cursor.com>

seanhanca · 2026-08-09T04:48:29Z

Scenario A prod e2e update (agent.livepeer.org)

OAuth = GREEN (2026-08-09T04:46Z)

Host: https://agent.livepeer.org ↔ NaaP https://operator.livepeer.org · test app app_98575870…
Human SSO callback returned mcp_ac_* + matching client state
Token endpoint 200 — token_type=Bearer, expires_in=86400, access_token prefix mcp_at_261… (secret not logged)
MCP initialize with that bearer 200
Root-cause fix live: livepeer/storyboard#881 (d29e161f) — Upstash auto-deserialize broke takePending → false invalid_state

create_media asset: first tools/call failed with -32602 (local harness omitted required action). Re-exchange of the same one-shot code → 400 {"error":"invalid_grant"}. Optional re-login for asset proof still available; harness patched.

Flip OFF now: delete Storyboard Production MCP_OAUTH_ENABLED → Redeploy.

E2E report: MCP-OAUTH-TRIMODE-E2E-REPORT.html on feat/mcp-oauth-tri-mode-plan (7190d21c).

SSO → token → create_media returned a real fal image URL; remind Flip-OFF. Co-authored-by: Cursor <cursoragent@cursor.com>

seanhanca · 2026-08-09T04:49:59Z

Scenario A = GREEN end-to-end ✅

Flip OFF now: delete Storyboard Production MCP_OAUTH_ENABLED → Redeploy.

Evidence (2026-08-09T04:49:29Z, no secrets):

SSO → mcp_ac_* → token 200 (mcp_at_1xk…, expires_in=86400)
MCP initialize 200
create_media action=generate 200
Asset: https://v3b.fal.media/files/b/0aa59a49/OPfu9uKMx82zolqCboa2J.jpg (~$0.003)

Hosts: agent.livepeer.org ↔ operator.livepeer.org · test app app_98575870…
Fix: storyboard#881 (d29e161f)

E2E report updated on feat/mcp-oauth-tri-mode-plan.

seanhanca · 2026-08-09T04:50:12Z

Scenario A = FULL GREEN ✅

Flip OFF now: delete Storyboard Production MCP_OAUTH_ENABLED → Redeploy.

Step	Result
SSO → Storyboard callback	`mcp_ac_*` + matching client `state` (04:49:29Z)
Token `POST /api/mcp/oauth/token`	200 · `Bearer` · `expires_in=86400` · prefix `mcp_at_1xk…`
MCP `initialize`	200
`create_media` `action=generate` (flux-schnell)	200 · ~$0.003

Asset: https://v3b.fal.media/files/b/0aa59a49/OPfu9uKMx82zolqCboa2J.jpg

Hosts: agent.livepeer.org ↔ operator.livepeer.org · test app app_98575870…
Fix: storyboard#881 (d29e161f)
E2E report: MCP-OAUTH-TRIMODE-E2E-REPORT.html on feat/mcp-oauth-tri-mode-plan (288b46ba)

github-actions · 2026-08-16T06:09:33Z

This PR has been inactive for 7 days. It will be closed in 5 days if no activity occurs. Feel free to reopen anytime.

seanhanca and others added 2 commits August 7, 2026 17:06

github-actions Bot added the size/XL Extra large PR (500+ lines) label Aug 8, 2026

vercel Bot deployed to Preview August 8, 2026 07:36 View deployment

seanhanca mentioned this pull request Aug 8, 2026

test(mcp-oauth): PR-01 — golden auth invariants INV-1…INV-6 livepeer/storyboard#868

Merged

6 tasks

vercel Bot deployed to Preview August 8, 2026 07:41 View deployment

vercel Bot deployed to Preview August 8, 2026 16:03 View deployment

docs(mcp-oauth): sign Track 2 progress + T-KV provisioning blocker

6ac94b3

Record PR-04/PR-05 merge SHAs, PR-06 open behind T-KV, and the project-scoped token limitation blocking Upstash Marketplace create.

vercel Bot deployed to Preview August 8, 2026 16:46 View deployment

docs(mcp-oauth): sign off T-KV — Upstash Redis wired prod+preview

8704fb3

Owner-provisioned store smoke-tested; PR-06 merge gate cleared. Co-authored-by: Cursor <cursoragent@cursor.com>

vercel Bot deployed to Preview August 8, 2026 18:03 View deployment

seanhanca and others added 2 commits August 8, 2026 11:24

docs(mcp-oauth): Track 2 complete; PR-09 open; OA-1 received

d47d197

Record PR-06/07/08 merge SHAs, T-KV already signed off, PR-09 naap#458 open, and OA-1 secret received with NaaP Preview env-wire still pending. Co-authored-by: Cursor <cursoragent@cursor.com>

docs(mcp-oauth): note PR-10 storyboard#876 open

803948f

Co-authored-by: Cursor <cursoragent@cursor.com>

vercel Bot deployed to Preview August 8, 2026 18:28 View deployment

seanhanca and others added 2 commits August 8, 2026 11:28

docs(mcp-oauth): mention PR-10 in Track 2/3 progress note

2d02ddc

Co-authored-by: Cursor <cursoragent@cursor.com>

docs(mcp-oauth): PR-09 merged (49d95d0)

8503aa5

Co-authored-by: Cursor <cursoragent@cursor.com>

vercel Bot deployed to Preview August 8, 2026 18:32 View deployment

docs(mcp-oauth): PR-10 merged on storyboard

6dbda43

Co-authored-by: Cursor <cursoragent@cursor.com>

vercel Bot deployed to Preview August 8, 2026 18:36 View deployment

vercel Bot deployed to Preview August 8, 2026 21:08 View deployment

docs(mcp-oauth): mark impl PRs complete; expand ops-only guides

d2b46b6

STATUS + plan: PR-11/12/15/16 + NaaP login bridge merged; remaining work is Preview env, web_ client, LR canary deploy, and deferred PR-13/17/FU-1.

vercel Bot deployed to Preview August 9, 2026 01:22 View deployment

vercel Bot deployed to Preview August 9, 2026 02:56 View deployment

docs(mcp-oauth): Production flip Scenario A e2e = BLOCKED

6c9ecff

Flag ON confirmed (AS/PRM 200); PKCE blocked on Storyboard client redirect allowlist + NaaP login mcp_oauth_invalid. Tripwire: delete MCP_OAUTH_ENABLED. Co-authored-by: Cursor <cursoragent@cursor.com>

vercel Bot deployed to Preview August 9, 2026 03:09 View deployment

docs(mcp-oauth): correct prod MCP host to agent.livepeer.org

beded0c

Scenario A re-probe: flag ON + NaaP allowlist OK; e2e still BLOCKED on Storyboard MCP_OAUTH_REDIRECT_ALLOWLIST. Remind flip OFF after test. Co-authored-by: Cursor <cursoragent@cursor.com>

vercel Bot deployed to Preview August 9, 2026 03:15 View deployment

vercel Bot deployed to Preview August 9, 2026 03:21 View deployment

docs(mcp-oauth): access_denied RCA + storyboard #880 reason ship

f6f0220

Record 3× Google SSO → opaque callback access_denied, live curls, and the Storyboard PR that returns a safe reason enum for the next retry. Co-authored-by: Cursor <cursoragent@cursor.com>

vercel Bot deployed to Preview August 9, 2026 04:06 View deployment

docs(mcp-oauth): confirm storyboard #880 reason live in Production

a0e07b0

Co-authored-by: Cursor <cursoragent@cursor.com>

vercel Bot deployed to Preview August 9, 2026 04:09 View deployment

docs(mcp-oauth): fresh authorize + durable listener for reason-coded …

aa5d9b2

…retry Co-authored-by: Cursor <cursoragent@cursor.com>

vercel Bot deployed to Preview August 9, 2026 04:11 View deployment

docs(mcp-oauth): refresh authorize URL after TTL window

d7edb7c

Co-authored-by: Cursor <cursoragent@cursor.com>

vercel Bot deployed to Preview August 9, 2026 04:21 View deployment

docs(e2e): Scenario A full GREEN — create_media asset on mcp_at

288b46b

SSO → token → create_media returned a real fal image URL; remind Flip-OFF. Co-authored-by: Cursor <cursoragent@cursor.com>

vercel Bot deployed to Preview August 9, 2026 04:52 View deployment

github-actions Bot added the stale No recent activity label Aug 16, 2026

Uh oh!

Conversation

seanhanca commented Aug 8, 2026

Purpose

Review verdict

The 17 PRs by track

No-regression guarantee

Top risks

Owner decisions folded in (2026-08-08)

Remaining open asks

Uh oh!

vercel Bot commented Aug 8, 2026 • edited Loading Uh oh! There was an error while loading. Please reload this page.

Uh oh!

Uh oh!

github-actions Bot commented Aug 8, 2026 • edited Loading Uh oh! There was an error while loading. Please reload this page.

Uh oh!

Uh oh!

seanhanca commented Aug 8, 2026

Uh oh!

seanhanca commented Aug 8, 2026

Uh oh!

seanhanca commented Aug 9, 2026

Implementation complete (code) — ops remaining

Uh oh!

seanhanca commented Aug 9, 2026

Scenario A Production flip probe (2026-08-09T03:05–03:07Z) — BLOCKED

Evidence

One-line fixes (if you re-open the window)

Uh oh!

seanhanca commented Aug 9, 2026

Prod host correction + Scenario A re-probe (2026-08-09T03:11Z)

Probe results

E2E status: BLOCKED (not GREEN)

Corrected Storyboard Production env (copy-paste)

Remind

Uh oh!

seanhanca commented Aug 9, 2026

Scenario A prod re-probe (allowlist fixed) — BLOCKED (not GREEN)

Evidence

Why not GREEN

Flip OFF now

Uh oh!

seanhanca commented Aug 9, 2026

Scenario A prod update — opaque access_denied + storyboard reason ship

Next user action (ONE retry after prod shows reason)

Uh oh!

seanhanca commented Aug 9, 2026

Production reason enum is LIVE

ONE retry URL (fresh pending, ~10 min TTL)

Uh oh!

seanhanca commented Aug 9, 2026

Fresh retry ready (reason codes LIVE + durable listener)

Uh oh!

seanhanca commented Aug 9, 2026

Fresh retry URL (re-minted — prior pending expired unused)

Uh oh!

seanhanca commented Aug 9, 2026

Scenario A prod e2e update (agent.livepeer.org)

Uh oh!

seanhanca commented Aug 9, 2026

Scenario A = GREEN end-to-end ✅

Uh oh!

seanhanca commented Aug 9, 2026

Scenario A = FULL GREEN ✅

Uh oh!

github-actions Bot commented Aug 16, 2026

Uh oh!

Reviewers

Assignees

Labels

Projects

Milestone

Development

Uh oh!

1 participant

vercel Bot commented Aug 8, 2026 •

edited

Loading

github-actions Bot commented Aug 8, 2026 •

edited

Loading

Scenario A prod update — opaque `access_denied` + storyboard reason ship

Next user action (ONE retry after prod shows `reason`)
