[None][feat] Qwen-Image: load pre-quantized ModelOpt NVFP4/FP8 checkpoints#15470
Open
jingyu-ml wants to merge 1 commit into
Open
[None][feat] Qwen-Image: load pre-quantized ModelOpt NVFP4/FP8 checkpoints#15470jingyu-ml wants to merge 1 commit into
jingyu-ml wants to merge 1 commit into
Conversation
…oints
Enable VisualGen to run Qwen-Image from a statically pre-quantized ModelOpt
checkpoint (NVFP4/FP8), and add the offline example + configs. Previously only
dynamic quantization (BF16 -> NVFP4 at load) worked; pointing --model at a
ModelOpt-exported NVFP4 checkpoint failed during weight loading.
transformer_qwen_image.py:
- Honor the checkpoint's quantization `ignore` list: clear quant_config on the
excluded Linear modules before create_weights() so they build the unquantized
method (ModelOpt stores those layers -- embedders, proj_out, norm_out,
time_text_embed, first/last blocks -- in BF16). get_quant_method() selects the
method purely from module.quant_config.
- Relax the strict weight-key check for FP8/NVFP4 helper buffers that are
derived at load time and never serialized (alpha, inv_input_scale, kv_scales,
inv_kv_scales).
Both changes are backward compatible with the dynamic-quant and BF16 paths.
Add examples/visual_gen/models/qwen_image.py and qwen-image-{fp4,bf16}-1gpu.yaml;
document static-checkpoint support in README and visual-generation.md; add a
unit test for the exclusion logic.
Validated on GB200 (sm_100): a static NVFP4 checkpoint loads (729/729 weights)
and renders a 1328x1328 image on par with BF16; qwen registry tests pass (7/7).
Signed-off-by: Jingyu Xin <jingyux@nvidia.com>
Contributor
📝 WalkthroughWalkthroughAdds support for loading pre-quantized ModelOpt FP8/NVFP4 checkpoints into ChangesQwen-Image static quantization loading and examples
Estimated code review effort🎯 3 (Moderate) | ⏱️ ~20 minutes Suggested labels
Suggested reviewers
🚥 Pre-merge checks | ✅ 4 | ❌ 1❌ Failed checks (1 warning)
✅ Passed checks (4 passed)
✏️ Tip: You can configure your own custom pre-merge checks in the settings. ✨ Finishing Touches🧪 Generate unit tests (beta)
Comment |
![coderabbitai[bot]](https://avatars.githubusercontent.com/in/347564?s=60&v=4){kind=small}
Contributor
There was a problem hiding this comment.
Actionable comments posted: 1
🧹 Nitpick comments (1)
tests/unittest/_torch/visual_gen/test_qwen_image_registry.py (1)
68-109: ⚡ Quick winCoverage is currently insufficient for the second loader behavior.
This test covers excluded-layer
quant_configclearing, but it does not exercise the new strict key-check relaxation for derived suffixes (.alpha,.inv_input_scale,.kv_scales,.inv_kv_scales) added inload_weights(). Please add a focused unit test intests/unittest/_torch/visual_gen/test_qwen_image_registry.py(or a dedicatedtest_qwen_image_transformer_load.py) that verifies:
- missing only derived keys does not raise in static mode, and
- missing a real weight key still does raise.
As per coding guidelines, tests under
tests/**should provide actionable coverage assessment for changed behavior.🤖 Prompt for AI Agents
Verify each finding against current code. Fix only still-valid issues, skip the rest with a brief reason, keep changes minimal, and validate. In `@tests/unittest/_torch/visual_gen/test_qwen_image_registry.py` around lines 68 - 109, Add a new focused unit test (either in the existing test_qwen_image_registry.py file or in a dedicated test_qwen_image_transformer_load.py file) that validates the strict key-check relaxation in the load_weights() method for derived suffix keys. The test should verify two scenarios: first, loading a checkpoint with missing only derived keys like .alpha, .inv_input_scale, .kv_scales, and .inv_kv_scales in static quantization mode should not raise an error, and second, loading a checkpoint with missing actual weight keys should still raise an error as expected. This ensures the key-check relaxation only applies to the derived suffixes and not to real weight keys.Source: Coding guidelines
🤖 Prompt for all review comments with AI agents
Verify each finding against current code. Fix only still-valid issues, skip the
rest with a brief reason, keep changes minimal, and validate.
Inline comments:
In `@tensorrt_llm/_torch/visual_gen/models/qwen_image/transformer_qwen_image.py`:
- Around line 889-909: The method `_clear_quant_config_on_excluded_layers()`
documents that it must run before any `create_weights()` call, but currently
runs in `load_weights()` which is too late. If
`skip_create_weights_in_init=False` allows excluded Linear modules to create
weights during `__init__`, clearing the quant_config later in `load_weights()`
won't switch them back to unquantized since `create_weights()` becomes a no-op.
Move the call to `_clear_quant_config_on_excluded_layers()` to run earlier in
the initialization sequence, such as right after the parent class `__init__`
completes or before weights can be created, to enforce the documented
precondition and ensure excluded layers use the correct unquantized
configuration.
---
Nitpick comments:
In `@tests/unittest/_torch/visual_gen/test_qwen_image_registry.py`:
- Around line 68-109: Add a new focused unit test (either in the existing
test_qwen_image_registry.py file or in a dedicated
test_qwen_image_transformer_load.py file) that validates the strict key-check
relaxation in the load_weights() method for derived suffix keys. The test should
verify two scenarios: first, loading a checkpoint with missing only derived keys
like .alpha, .inv_input_scale, .kv_scales, and .inv_kv_scales in static
quantization mode should not raise an error, and second, loading a checkpoint
with missing actual weight keys should still raise an error as expected. This
ensures the key-check relaxation only applies to the derived suffixes and not to
real weight keys.
🪄 Autofix (Beta)
Fix all unresolved CodeRabbit comments on this PR:
- Push a commit to this branch (recommended)
- Create a new PR with the fixes
ℹ️ Review info
⚙️ Run configuration
Configuration used: Path: .coderabbit.yaml
Review profile: CHILL
Plan: Enterprise
Run ID: 173a44f7-5ae5-44ca-897f-f445dda939bb
📒 Files selected for processing (7)
docs/source/models/visual-generation.mdexamples/visual_gen/README.mdexamples/visual_gen/configs/qwen-image-bf16-1gpu.yamlexamples/visual_gen/configs/qwen-image-fp4-1gpu.yamlexamples/visual_gen/models/qwen_image.pytensorrt_llm/_torch/visual_gen/models/qwen_image/transformer_qwen_image.pytests/unittest/_torch/visual_gen/test_qwen_image_registry.py
Comment on lines
+889
to
+909
| def _clear_quant_config_on_excluded_layers(self) -> None: | ||
| """Build the checkpoint's excluded layers as unquantized. | ||
|
|
||
| ModelOpt keeps some layers in high precision (the ``ignore`` list in | ||
| the checkpoint's ``quantization_config`` -- e.g. img_in / txt_in / | ||
| proj_out / norm_out / time_text_embed and the first/last transformer | ||
| blocks), storing plain BF16 weights with no scales for them. | ||
| ``get_quant_method()`` selects the Linear method purely from | ||
| ``module.quant_config``, so clear it on the excluded Linear modules to | ||
| fall back to the unquantized method. Must run before any | ||
| ``create_weights()`` call, since parent modules (e.g. ``MLP``) may | ||
| materialize their child Linears eagerly. | ||
| """ | ||
| quant_config = self.model_config.quant_config | ||
| if quant_config is None or quant_config.quant_algo is None: | ||
| return | ||
| for name, module in self.named_modules(): | ||
| if (isinstance(module, Linear) | ||
| and quant_config.is_module_excluded_from_quantization(name)): | ||
| module.quant_config = None | ||
|
|
Contributor
There was a problem hiding this comment.
Enforce the “before create_weights” precondition to avoid stale quantized layouts.
_clear_quant_config_on_excluded_layers() runs in load_weights(), but if any excluded Linear already created weights during __init__ (e.g., skip_create_weights_in_init=False), clearing quant_config on Line 908 won’t switch it back to unquantized because later create_weights() is a no-op. That can still mis-handle BF16 excluded layers.
Suggested fix
def _clear_quant_config_on_excluded_layers(self) -> None:
@@
- for name, module in self.named_modules():
- if (isinstance(module, Linear)
- and quant_config.is_module_excluded_from_quantization(name)):
- module.quant_config = None
+ already_materialized: list[str] = []
+ for name, module in self.named_modules():
+ if not isinstance(module, Linear):
+ continue
+ if not quant_config.is_module_excluded_from_quantization(name):
+ continue
+ if getattr(module, "_weights_created", False):
+ already_materialized.append(name)
+ module.quant_config = None
+
+ if already_materialized:
+ raise RuntimeError(
+ "Excluded layers already materialized quantized weights before quant_config "
+ f"clear: {already_materialized[:5]}. Construct with "
+ "skip_create_weights_in_init=True for static quantized checkpoints."
+ )Also applies to: 919-924
🤖 Prompt for AI Agents
Verify each finding against current code. Fix only still-valid issues, skip the
rest with a brief reason, keep changes minimal, and validate.
In `@tensorrt_llm/_torch/visual_gen/models/qwen_image/transformer_qwen_image.py`
around lines 889 - 909, The method `_clear_quant_config_on_excluded_layers()`
documents that it must run before any `create_weights()` call, but currently
runs in `load_weights()` which is too late. If
`skip_create_weights_in_init=False` allows excluded Linear modules to create
weights during `__init__`, clearing the quant_config later in `load_weights()`
won't switch them back to unquantized since `create_weights()` becomes a no-op.
Move the call to `_clear_quant_config_on_excluded_layers()` to run earlier in
the initialization sequence, such as right after the parent class `__init__`
completes or before weights can be created, to enforce the documented
precondition and ensure excluded layers use the correct unquantized
configuration.
Author
Qwen-Image NVFP4 latency sweep — batch × resolution × GEMM backend (GB200 / sm_100)Follow-up benchmarks for this PR. Per-image latency, median, 50 steps, TL;DR
1024×1024
1328×1328
1536×1536
NVFP4 (best backend) vs BF16 — speedup (×, <1 = NVFP4 faster)
Note: cutedsl backend omitted — its CuteDSL NVFP4 JIT build is impractical for this model (>8 min/shape). W4A4 NVFP4 has no trtllm-gen cubin backend; |
This file contains hidden or bidirectional Unicode text that may be interpreted or compiled differently than what appears below. To review, open the file in an editor that reveals hidden Unicode characters.
Learn more about bidirectional Unicode characters
Sign up for free
to join this conversation on GitHub.
Already have an account?
Sign in to comment
1 participant
Add this suggestion to a batch that can be applied as a single commit.This suggestion is invalid because no changes were made to the code.Suggestions cannot be applied while the pull request is closed.Suggestions cannot be applied while viewing a subset of changes.Only one suggestion per line can be applied in a batch.Add this suggestion to a batch that can be applied as a single commit.Applying suggestions on deleted lines is not supported.You must change the existing code in this line in order to create a valid suggestion.Outdated suggestions cannot be applied.This suggestion has been applied or marked resolved.Suggestions cannot be applied from pending reviews.Suggestions cannot be applied on multi-line comments.Suggestions cannot be applied while the pull request is queued to merge.Suggestion cannot be applied right now. Please check back later.
What does this PR do?
Type of change: New feature / bug fix
Enables TensorRT-LLM VisualGen to run Qwen-Image from a pre-quantized
ModelOpt checkpoint (static NVFP4 / FP8), and adds the missing offline
example + configs. Previously Qwen-Image only supported dynamic quantization
(quantize a BF16 checkpoint at load); pointing
--modelat a ModelOpt-exportedNVFP4 checkpoint failed during weight loading.
Loader fix (
transformer_qwen_image.py):ignorelist. ModelOpt keeps the embedders(
img_in/txt_in),proj_out,norm_out,time_text_embed, and thefirst/last transformer blocks in BF16.
get_quant_method()selects theLinear method purely from
module.quant_config, so excludedLinears nowhave it cleared (→ unquantized method) before
create_weights(). Withoutthis they were built as NVFP4 and their BF16 weights failed to load.
at load time and never serialized (
alpha,inv_input_scale,kv_scales,inv_kv_scales).Both changes are backward compatible: the dynamic BF16→NVFP4 path
(
dynamic_weight_quant=True, noignorelist) is unaffected.Examples / docs:
examples/visual_gen/models/qwen_image.py— offline text-to-image example(mirrors
flux1.py).examples/visual_gen/configs/qwen-image-fp4-1gpu.yaml,qwen-image-bf16-1gpu.yaml.are now supported for Qwen-Image.
Usage
Output samples
NVFP4 image quality is on par with BF16 (1328×1328, 50 steps, seed 42, same prompt):
Qwen/Qwen-Image)Testing
On 1× GB200 (sm_100), TRT-LLM release container:
New unit test
test_static_quant_excludes_high_precision_layers+ existingtests/unittest/_torch/visual_gen/test_qwen_image_registry.py— 7 passed.End-to-end: a ModelOpt static NVFP4 checkpoint loads (729/729 weights) and
produces a prompt-faithful 1328² image, visually on par with BF16 (same seed).
Latency on 1× GB200 (1328², 50 steps, torch.compile on, median per image):
NVFP4 gives a ~3× smaller transformer (13 GB vs ~40 GB BF16) and is ~12 %
faster per image in the batched regime (batch ≥ 2) at equal quality. The
batch-1 case is slower only because NVFP4's per-call FP4 activation-quant +
graph-break overhead isn't amortized there. Among the W4A4 NVFP4 GEMM
backends,
cublasltis fastest; there is no trtllm-gen cubin for W4A4 (thatpath is W4A8, needing a different checkpoint).
