Original file line number | Diff line number | Diff line change |
---|---|---|
@@ -0,0 +1,141 @@ | ||
|
||
## 处理图片加载 | ||
|
||
1. 懒加载 | ||
2. 响应式图片自动匹配尺寸 | ||
|
||
> https://github.com/aFarkas/lazysizes | ||
## 生成图片资源 | ||
|
||
通过gulp生成响应式图片的方法,限于篇幅,这里只生成了90,180和360和原始图片。实际推荐生成以下宽度的图片90, 180, 360, 540, 720, 900, 1080, 1296, 1512, 1728, 2048。以便覆盖从小屏幕到大屏幕的大部分情况(包括设备分辨率为2x的情况)。 | ||
|
||
> *可以考虑生成32像素以下图片,用来做低分辨率的占位图 | ||
1.安装gulp, gulp-responsive | ||
|
||
```shell | ||
yarn add --dev gulp | ||
yarn add --dev gulp-responsive | ||
``` | ||
|
||
2.编写 `gulpfile.js`,如下所示 | ||
|
||
```javascript | ||
var gulp = require('gulp') | ||
var responsive = require('gulp-responsive') | ||
gulp.task('default', function (){ | ||
return gulp | ||
.src('images/*.{png, jpg}') | ||
.pipe( | ||
responsive({ | ||
'*': [ | ||
{ | ||
width: 90, | ||
quality: 50, | ||
rename:{ | ||
suffix:'-90' | ||
} | ||
}, | ||
{ | ||
width: 180, | ||
quality: 75, | ||
rename:{ | ||
suffix:'-180' | ||
} | ||
}, | ||
{ | ||
width: 360, | ||
rename: { | ||
suffix:'-360' | ||
} | ||
}, | ||
{ | ||
rename: { | ||
suffix: '-original' | ||
} | ||
} | ||
] | ||
}, { | ||
errorOnEnlargement: false, | ||
skipOnEnlargement: true, | ||
withoutEnlargement: true | ||
}) | ||
) | ||
.pipe(gulp.dest('dist/images')) | ||
}) | ||
``` | ||
|
||
3.`npx gulp` 生成目标图片 | ||
|
||
## 配置使用 | ||
|
||
1. 初始化配置(对背景图片懒加载处理) | ||
|
||
```html | ||
<script> | ||
function LoadJS(u) { | ||
var r = document.getELementsByTagName("script")[0], | ||
s = document.createElement("script"); | ||
s.src = u; | ||
r.parentNode.insertBefore(s, r); | ||
} | ||
if (!window.HTMLPictureELement) { | ||
loadJS("js/ls. resp img.min.js"); | ||
} | ||
</script> | ||
<script src="https://afarkas.github.io/lazysizes/plugins/bgset/ls.bgset.min.js"></script> | ||
<script src="js/lazysizes.min. js" async></script> | ||
``` | ||
2. 修改图片引用 | ||
|
||
```html | ||
<img | ||
class="img-fluid lazyload" | ||
data-src="dist/images/p2604517782-32.jpg" | ||
data-srcset="dist/images/p2684517782-98.jpg 90w,dist/images/p2604517782-188.jpg 180w,dist/images/p2604517782-original.jpg" data-sizes="auto" alt="" | ||
> | ||
``` | ||
|
||
3. 对背景的引用(注意引入依赖插件) | ||
|
||
```html | ||
<section | ||
class="banner lazyload" | ||
data-bgset="dist/images/sky-540.jpg 540w, dist/images/sky-1080.jpg 1080w, dist/images/sky-original.jpg" | ||
data-sizes="auto"> | ||
</section> | ||
``` | ||
|
||
相关示例: | ||
|
||
1. https://github.com/aFarkas/lazysizes | ||
2. https://jsfiddle.net/trixta/bfqqnosp/ | ||
3. https://github.com/aFarkas/lazysizes/tree/e305d28d4b6c4ff9f12dd4d438d5d7c5d41574db/plugins/bgset | ||
|
||
|
||
## 其他注意点 | ||
|
||
移动设备优先: 确保适当的绘制和触屏缩放,需要在网页的 head 之中添加 viewport meta 标签,如下所示: | ||
```html | ||
<meta name="viewport" content="width=device-width, initial-scale=1, shrink-to-fit=no"> | ||
``` | ||
width-device-width 表示宽度是设备屏幕的宽度。 | ||
|
||
initial-scale-1 表示初始的缩放比例。 | ||
|
||
shrink-to-fit=no 自动适应手机屏幕的宽度。 | ||
|
||
## 效果测试 | ||
|
||
### 手动测试 | ||
|
||
使用Chrome自带的移动端调试功能 | ||
|
||
### 自动测试 | ||
|
||
Chrome的手动测试主要在方便开发者调试,最终还是要保证在用户的真机上可以正常浏览。可以像开头图片显示的,整一些手机做测试,但是没有群控的话,测试效率过低,做群控本身工程量也不小。因此,一般推荐直接使用相关的云服务,比如BrowserStack。 | ||
|
||
资源链接:[BrowserStack](https://www.browserstack.com/screenshots) | ||
|
||
![img](https://cdn.jsdelivr.net/gh/HarryPoint/oss@main/uPic/2024-07-24_10:57:34_LXPdQC.png) |
